Technical specifications技術(shù)規(guī)格：

Input輸入:

AC socket交流輸入接口: C6  梅花尾

Input range輸入電壓范圍：90Vac~264Vac

Frequency頻率：47Hz~63Hz

Input current輸入電流：1.9A Max at 100Vac input voltage

Efficiency效率：89% Min. at nominal input voltage, maximum load and measured at the end of DC cable

Output輸出

Output Power輸出功率：135W

Output Volts/Amps輸出電壓/電流：20V 6.75A

Output ripple and noise輸出紋波：350 mV peak to peak

DC plug輸出接口: do it follow up customer request 按照客戶項(xiàng)目需求提供

Dimensions 尺寸(mm)

L145.0 x W65.0 x H30.0
