Input輸入:

AC Socket輸入接口:美規，中規，歐規，英規    US, CHINA, EU,UK

Input range輸入電壓范圍：90Vac~264Vac

Frequency頻率：47Hz~63Hz

Input current輸入電流：1.2A Max at 100Vac input voltage

Efficiency效率：86% Min. at nominal input voltage, maximum load and measured at the end of DC cable

Output輸出

Output Power輸出功率：45W

Output Volts/Amps輸出電壓/電流：19.0V/2.37A

Output ripple and noise輸出紋波：350 mV peak to peak

DC Plug輸出接口:  follow up customer request to do  按照客戶項目需求提供

Dimensions (mm)尺寸

L63.0 x W63.0 x H28.5
