Technical specifications技術(shù)規(guī)格：

Input輸入:

AC Socket交流輸入接口:  C14 品字尾

Input range交流電壓輸入范圍：90Vac~264Vac

Frequency頻率：47Hz~63Hz

Input current輸入電流：3.5A Max at 100Vac input voltage

Efficiency效率：88% Min. at nominal input voltage, maximum load and measured at the end of DC cable

Output輸出

Output Power輸出功率：280W

Output Volts/Amps輸出電壓/電流：20.0V/14A

Output ripple and noise輸出紋波：350 mV peak to peak

DC Plug輸出接口: do it follow up customer request  按照客戶項(xiàng)目需求提供

Dimensions尺寸 (mm)

L180.0 x W85.0 x H35
